Includes 1-right hand thread 1-Left hand thread Heim set. Spacers Jam nuts and tube adapters included
1-piece design Heat Treated steel, 3/4?? 16tpi Thread
Never needs grease
28,000 Pound static load rating
Bar Kit with Spacer Specifications
Rod End
steel
Thread Size: 3/4″-16
Ball Bore: 0.750″
Ball Width: 0.875″
Centerline Length: 2.875″
Thread Length: 1.750″
Load Capacity: 28,000 lbs
Bung
Thread Size: 3/4″-16
Fits Tube Size: 1 1/4″ OD x 0.095 Tubing
Spacers
Insert Diameter: .750″
Inside Bore: .625″
Outside Diameter: .950″
