1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH
1/2 X 1/2-20 Economy Panhard Bar Kit with Bung .065, Rod End, Heim Joint LH + RH
1 Right Hand & 1 Left Hand
Rod End Body Material: C1045 Steel Heat Treated, Silver Zinc Plated
Rod End Ball Material: 52100 Bearing Steel Precision Ground Heat Treated, Hard Chrome Plated
Jam Nut Specs: Thread: 1/2-20, Width: 0.302-0.323, Height: 0.736-0.750
Bar Kit Specifications
Rod End
Thread Size: 1/2″-20
Ball Bore: 0.500″
Ball Width: 0.625″
Centerline Length: 2.438″
Thread Length: 1.500″
Load Capacity: 12,224 lbs
Bung
Material: 1045 Steel
Thread Size: 1/2″-20
Fits Tube Size: 1″ OD. x .065″ Wall x 0.85″ ID
Jam Nut
Thread Size: 1/2″-20
Width: 3/4″
Height: 5/16″
